Knurling Tools (Knurling Holders and Knurling Wheels)

Features:

• Recommended for RAA type knurling
• For knurling up to a shoulder (Fig. 1)HSS bushing
• Able to fit on right-hand or left-hand (Fig. 2)
• Anti-wearing treatment of the tool surface
• Adjustment of tool clearance angle by threaded studs integrated in the shank
• Supplied with a HSS hardened washer to prevent tool wearing

Features:

• Recommended for RGE type knurling
• For knurling up to a shoulder (Fig. 1)
• Pivoting head for knurls self-centering (Fig. 2)
• HSS bushings
• Anti-wearing treatment of the tool surface
• Adjustment of tool clearance angle by threaded studs integrated in the shank

Features:

• Recommended for RAA type knurling
• For internal knurling
• HSS bushing
• Supplied with a HSS hardened washer to prevent tool wearing

Features:

• Recommended for RAA type knurling
• Carbide pin
• Anti-wearing treatment of the tool surface
• Adjustment of tool clearance angle by threaded studs integrated in the shank

Features:

• Recommended for RGE type knurling
• Pivoting head for knurls self-centering (Fig. 1)
• Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 2)
• Carbide pins
• Anti-wearing treatment surface
• Adjustment of tool clearance angle by threaded studs integrated in the shank

Features:

• Recommended for RGE type knurling
• Pivoting head for knurls self-centering (Fig. 1)
• For non-repetitive works
• HSS pins fixed by circlip

Machine Types:

• For conventional and CNC lathes

Features:

• Recommended for RGE type knurling
• Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
• Up & down tool head alignment for knurls centering (Fig. 1)
• Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 3)
• HSS TIN bushing
• Adjustment of tool clearance angle by threaded studs integrated in the shank

Features:

• Recommended for RAA type knurling
• Pivoting head for knurl alignment (Fig. 1)
• Tool with reversible head able to fit on lefthand or right-hand lathes (Fig. 2)
• HSS TIN bushing
• Adjustment of tool clearance angle by threaded studs integrated in the shank

Features:

• Recommended for RAA type knurling
• Carbide pin
• Anti-wearing treatment of the tool surface
• Adjustment of tool clearance angle by threaded studs integrated in the shank
